AW00123409000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 23
Specification acA3800-14um/uc acA4600-10uc
Resolution
(H x V pixels)
um: 3840 x 2748
uc: 3840 x 2748
uc: 4608 x 3288
Sensor Type Aptina MT9J003
Progressive scan CMOS
Rolling shutter
Aptina MT9F002
Progressive scan CMOS
Rolling shutter
Optical Size 1/2.3"
Effective Sensor Diagonal 7.9 mm 8.0 mm
Pixel Size (H x V) 1.67 µm x 1.67 µm 1.4 µm x 1.4 µm
Max. Frame Rate 14 fps (at full resolution) 10 fps (at full resolution)
Mono/Color Mono or color (color models include a
Bayer pattern RGB filter on the sensor)
Color (includes a Bayer pattern RGB
filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Model:
Mono 8 Mono 12p
Mono 12
Color Model:
Mono 8 Bayer BG 12p
Bayer BG 8 YCbCr422_8
Bayer BG 12
Color Model:
Mono 8 Bayer BG 12p
Bayer BG 8 YCbCr422_8
Bayer BG 12
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port
≈2.5 W (typical) @ 5 VDC, ≈2.8 W (max.)
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, 2 direct-coupled GPIO lines;
power supplies must meet the SELV and LPS requirements
Lens Mount C-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without cylindric housing extension or connectors)
48.2 mm x 29 mm x 29 mm (with cylindric C-mt. housing extension and connectors)
Weight <80 g
Conformity CE (includes RoHS), UL Listed, FCC, GenICam V. 2.x (includes PFNC V. 2.x and
SFNC V. 2.x), IP30, USB3 Vision, USB-IF in preparation, REACH
The EU Declaration of Conformity is available on the
Basler website: www.baslerweb.com
Software Basler pylon Camera Software Suite (version 4.0 or higher)
Available for Windows (x86, x64) and Linux (x86 32 bit, x86 64 bit, ARM).
Table 18: General Specifications
