Specifications, Requirements, and Precautions AW00123409000
22 Basler ace USB 3.0
Specification acA2500-60um acA2500-60uc
Resolution (H x V pixels) 2592 x 2048
Sensor Type
ON Semiconductor
®
PYTHON NOIP1SN5000A
Progressive scan CMOS
Global shutter
ON Semiconductor
®
PYTHON NOIP1SE5000A
Progressive scan CMOS
Global shutter
Optical Size 1"
Effective Sensor Diagonal 15.9 mm
Pixel Size (H x V) 4.8 µm x 4.8 µm
Max. Frame Rate
(at full resolution)
60 fps (at fast sensor readout and HiDLTL; see Section 1.2 on page 2)
47 fps (at normal sensor readout and HiDLTL; see Section 1.2 on page 2)
Mono/Color Mono or color (color cameras include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono 8 Mono 10p
Mono 10
Mono 8 RGB8
Bayer BG 8 BGR8
Bayer BG 10 YCbCr422_8
Bayer BG 10p
Synchronization Via hardware trigger, via software trigger or free run
Exposure Time Control Via hardware trigger or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC; SELV and LPS compliant and in accord with the Universal Serial
Bus 3.0 specification; supplied via the camera’s USB 3.0 port.
Mono Models:
≈3.6 W (typical) @ 5 VDC, ≈3.9 W (max.)
Color Models:
≈3.8 W (typical) @ 5 VDC, ≈4.1 W (max.)
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines; power supplies must meet the SELV and LPS requirements
Lens Mount C-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without cylindric housing extension or connectors)
48.2 mm x 29 mm x 29 mm (with cylindric housing extension and connectors)
Weight <80 g
Conformity CE (includes RoHS), UL in preparation, FCC, GenICam V. 2.x (includes PFNC V.
2.x and SFNC V. 2.x), IP30, USB3 Vision, USB-IF in preparation, REACH
The EU Declaration of Conformity is available on the Basler website:
www.baslerweb.com
Software Basler pylon Camera Software Suite (version 4.0 or higher)
Available for Windows (x86, x64) and Linux (x86 32 bit, x86 64 bit, ARM).
Table 17: General Specifications
