925.916.2 - GBINSTRUCTIONS PERTAINING TO THE INSTALLER
LUNA 3 SYSTEM HT 1.240 MP
Gas consumption at15 °C G20 - 2H - 20 mbar G31 - 3P - 37 mbar
1013 mbar
PCI 34.02 MJ/m
3
46.3 MJ/kg
Consumption at max. heat output 2.61 m
3
/h 1.92 kg/h
Consumption at min. heat output 0.74 m
3
/h 0.54 kg/h
Table 2b
LUNA 3 SYSTEM HT 1.180 MP
Gas consumption at 15 °C G20 - 2H - 20 mbar G31 - 3P - 37 mbar
1013 mbar
PCI 34.02 MJ/m
3
46.3 MJ/kg
Consumption at max. heat output 1.84 m
3
/h 1.35 kg/h
Consumption at min. heat output 0,44 m
3
/h 0,33 kg/h
Table 2c
LUNA 3 SYSTEM HT 1.330 MP
Gas consumption at 15 °C G20 - 2H - 20 mbar G31 - 3P - 37 mbar
1013 mbar
PCI 34.02 MJ/m
3
46.3 MJ/kg
Consumption at max. heat output 3.59 m
3
/h 2.64 kg/h
Consumption at min. heat output 1,06 m
3
/h 0.78 kg/h
Table 2a
CLOCKWISE Parameters 608 Parameters 611
Gas boiler model regulation screw (%) (rpm) (rpm)
(V) turns Gas G20 Gas G31 Gas G20 Gas G31
LUNA3 SYSTEM HT 1.330 MP 3 50 35 4200 3500
LUNA3 SYSTEM HT 1.240 MP 2 55 35 4600 4000
LUNA3 SYSTEM HT 1.180 MP 1 40 40 3900 3350
Table 3
