108 BD406/PBD406 DV16401.03 Issue 04 May 2021
BD406 without control head
When next message from same beacon is
received audio notification: ‘Beacon’ is
audible, and the antenna symbol is shown on
the screen for 0.5 second.
When a new message is received the outputs /MSG and /GPO_0 is active for 400 ms.
When a message from registered beacon is received again only /MSG is activated for 400 ms.
The device can store up to 49 different beacons.
When beacon database is full, and a received
message does not exist in beacon database
different warnings can be shown (warning
depends on configuration):
WARN-01:
WARN-01 01/03
NEW BEACON
OVERWRITES OLD
Press STO
to confirm
WARN-02:
WARN-02 01/03
NEW BEACON
IGNORED
Press STO
to confirm
• Push STO to execute the related action.
It is possible to gather 49 beacons in the
database. It corresponds to 49 frames
transmitted via target protocol when database is
full.
