Becker Avionics
Installation and Operation
Post Installation Check
DV16401.03 Issue 04 May 2021 BD406/PBD406 71
2.8 Post Installation Check
After the device/system is installed completely do a test. Make sure that the compliance with the
authority required procedures is obeyed.
The description that follows gives guidance for such tests.
Mechanical Installation and Wiring Check
Make sure that all cables are attached and the shields are connected to ground.
Examine the movement of controls to make sure that there is no interference.
Make sure that all screws are tight and the connectors of the device are secured.
Power Supply
Examine the power supply lines and the correct polarity.
Make sure that the power supply is in the specified limits, with and without an engine that
is in operation.
Activated Subsystems
Examine all subsystems which were activated during installation setup: e.g. audio
systems, transmission interfaces, etc.
Receiver Operation
Make sure the proper reception of the COSPAS/SARSAT signal.
It is recommended to use dedicated BT406 test setup for test signals in full permitted
range. For minimal test use a PLB set in self-test mode (refer to the manual of the related
PLB).
It is mandatory to follow all regulations regarding generation of
RF COSPAS/SARSAT distress signals.
If a PLB is used as a source of a test signal, it is not permitted to activate it
in live emergency mode.
Each emergency call instantly triggers a search and rescue operation.
Misuse is strenuously prosecuted and can incur claims for damages.
Unauthorized persons may not operate the PLB.
Antenna Check
Refer to antenna manual.
Interference Check
Examine the device/system while the engine is in operation and power-on all other
avionics/ electrical systems on the aircraft, to make sure that no significant interference
exists.
Examine that the device does not cause significant interference with other systems.
Do a check for interference between the VHF-COM and the GPS receiver used by BD406.
Is the reception be influenced by local interference, trace the source by systematically
power-off the electronic equipment, generators, etc. on the aircraft to find which
component is causing interference. Then suppress interference accordingly.
Typical sources of interference are: generators, regulators, static inverters, choppers,
DC converters, RF sources: transponders, DME, communication equipment.
