Operations from Beacons/NavPoints Details View
BD406 without control head: N/A
Operation
Description
Left key (LEXCH)
short push
Selects the page before with Beacon/NavPoint details (loop function).
Right key (REXCH)
short push
Selects next the page with Beacon/NavPoint details (loop function).
MDE key
short push
Toggles between Beacon Details and NavPoint Details view.
MDE key
long push
Starts Beacon Menu/NavPoint Menu view.
STO key
short push
Starts Beacon Course view/NavPoint Course view.
STO key
long press
Starts Config view.
Rotary knob
left/right turn
Selects the page before/next with Beacon/NavPoint (loop function).
Rotary knob
short push
Voice notification homing is generated (depends on configuration).
MDE + STO key
push
Starts GPS status mode.
Row ID
Display
Description - Beacon Details View
1
B 03/15
1/6
PT: STD-LOC
CNTR: 279 TAC: 0719
BT: EPIRB SN: 14000
S-T
Beacon detailed view:
PT: Protocol Type of the received message from selected
beacon.
STD-LOC: Standard Location Protocol,
NAT-LOC: National Location Protocol,
USER: User Protocol,
USER-LOC: User Location Protocol.
S-T flag is visible only if self-test message for related beacon is
active.
BT: Beacon Type of the received message from selected
beacon. Possible designators: EPIRB, PLB, ELT, SSAS, TEST.
SN: 5-digit Beacon Serial Number.
When unknown protocol is used: ----- is shown.
CNTR: 3-digit decimal country code from received message from
selected beacon.
TAC: 4-digit Type Approval Certificate Number (TAC).
If TAC is invalid: ---- is shown.
General Notice: Refer to COSPAS/SARSAT documents for definition of protocols,
beacon types, TAC. See COSPAS/SARSAT for definition of protocols.
