Becker BD406 - Dimensions & Weight - BD406; Dimensions & Weight - PBD406; Interfaces

General Description
Becker Avionics
Technical Data
26 BD406/PBD406 DV16401.03 Issue 04 May 2021
Interfaces
BD406
Specifications
BD406 with control head / PBD406
BD406 without control head
Serial interfaces
RS422 – for service purposes
n/a
RS422 – auxiliary port
(for future use)
n/a
RS232 – GPS external/internal data
transmission NMEA 0183 compliant
n/a
RS232 – Targets Status Protocol
RS232 – Targets Status Protocol
Baud rate : 19 200
Data bits: 8
Parity: none
Stop bits: 1
ARINC 429 output label 162
(ADF bearing)
n/a
Dimensions & Weight - BD406
BD406
Specifications
BD406 with control head / PBD406
BD406 without control head
Front panel HxW
61 x 61 x mm (2.4 x 2.4 in)
Device depth complete
230 mm (9 in)
190 mm (7.5 in)
Mounting depth
208.5 mm (7.5 in)
236 mm (9.29 in)
with mounting kit MK4401
Installation method
Rear panel
4x screws at front panel
Ø 58 mm (2¼ inch)
Avionic bay environment
2x Phillips head screw M4x8 at
the front plate for mounting in
MK4401
Weight
≤ 700 g
≤ 600 g
+ ≤ 130 g (mounting kit MK4401)
Material of Case /
Surface treatment
AlMg / control head coated with
black matt paint
AlMg
Dimensions & Weight - PBD406
PBD406
Specifications
Front panel HxW
83 x 174 mm (3.3 x 6.7 in)
Device depth complete
334 mm (13.1 in) with handle in maximal position
Installation method
Portable device
Weight
≤ 3700 g
