Becker BD406 - Bracket for Vehicle Installation; Figure 17: Dimensions - Bracket for Vehicle Installation

Installation
Becker Avionics
Dimensions
44 BD406/PBD406 DV16401.03 Issue 04 May 2021
Bracket for Vehicle Installation
Dimensions mm (inch)
Figure 17: Dimensions - Bracket for Vehicle Installation
Permitted deviation for dimensions without tolerances: DIN ISO 2768 T1 C (dimensions in mm)
xx...6 (±0.3)
>30...120 (±0.8)
>400...1000 (±2.0)
>6...30 (±0.5)
>120...400 (±1.2)
>1000...2000 (±3.0)
60 (2.4)
Ø10
(0.4)
Ø20
(0.8)
3
(0.1)
163 (6.4)
228 (9)
233 (9.2)
17.5
(0.7)
Section A-A
A
A
Y
Y
120 (4.7)
3x Ø 4.3 (0.17)
180 (7.1)
