Operation
Becker Avionics
98 BD406/PBD406 DV16401.03 Issue 04 May 2021
Row ID
Display
Description - Beacon Details View
2
B03/15
2/6
15HEX:
123 456 789
0AB CDE
15HexID designator view:
15HEX: 15HexID name with 15 characters string.
3
B
03
/
15
3
/
6
N 43
o
25
` ``
16
E 112
o
56
` ``
09
Beacon position:
If position is invalid: - (dash) signs are shown.
4
B
03
/
15
4/6
TBRG: 095
o
031.6 kmDIST:
TC: 123.6
o
Bearing, course, distance view:
TBRG: 3-digits true bearing (related to the true north).
Range 000…359 degrees.
TC: 4-digits device true course over ground taken from GPS
receiver.
Range 000.0…359.9 degrees.
DIST: 4-digits device distance to the target.
Range 000.0…999.9 distance units (kilometer km or nautical miles
NM).
If true bearing is invalid: --- is shown.
If distance to the target is invalid: ---.- is shown.
If true course over ground is invalid: ---.- is shown.
