AeroNav 900/880 Series Pilot’s Guide
89000039-010
Rev 1 May 2019 Map Subsystem 4-29
Onboard Weather Radar Overlay on Map
TIPS AND TECHNIQUES
Onboard Weather Radar Overlay Usage
There are no controls of the onboard weather radar
from the map page – it is simply an on/off layer. The
map can be decluttered to remove non-essential map
content but still provide map and flight plan graphical
situational awareness and a more typical weather radar
depiction at the same time.
Radar control is only available on the dedicated RADAR
tab.
