AeroNav 900/880 Series Pilot’s Guide
89000039-010
Rev 1 May 2019 System Overview 1-23
PAGE LAYOUT AND FORMATS
The context-sensitive line select keys, top datablocks and nav
source knob indication, and bottom edge set of page tabs are
always displayed on every page. The AeroNav 900 and AeroNav
910 will also show radio frequencies in the upper left corner. The
frequencies to be shown are configurable. For the AeroNav 880
and AeroNav 905, that area can be configured to show other
datablocks just like those on the right side of the page.
Page Layout (AeroNav 900 Shown)
Use a combination of the page function keys and the associated
tabs, to change the contents of the rest of the display.
Each page has a number of associated tabs. Each Page Function
key has a left and right rocker nature to it. To select a tab using
