AeroNav 900/880 Series Pilot’s Guide
89000039-010
Rev 1 May 2019 Map Subsystem 4-45
TAS Other Traffic
Traffic that is detected by the traffic sensor,
but determined not to be a current threat.
(hollow blue diamond)
TIS Traffic Alert (TA)
Traffic radiated by a TIS ground station and
includes 45 cardinal track pointers when
available. (solid blue diamond with blue
pointer barb)
TIS-B (ADS-B, ADS-R) Traffic Alert (TA)
Traffic that is within the alert zone defined by
the TIS-B traffic receiver and includes an
arrow shaped symbol that indicate the
target’s track. (yellow arrow head inside a
yellow circle with a 1 minute pointer barb)
TIS-B (ADS-B, ADS-R) Proximate Traffic
Traffic that is not within an alert zone, but is
close to your position. (blue solid arrow head
with a 1 minute pointer barb)
TIS-B (ADS-B, ADS-R) Other Traffic
Traffic that is detected by the TIS-B traffic
receiver, but determined not to be a current
threat. (blue hollow arrow head with a 1
minute pointer barb)
