Inactive missed approach procedures are depicted as dashed lines,
just like on the 2D map and go solid when/if the missed approach
procedure has been activated.
Missed Approach (Not Activated) in Map SVS View
Landing airfields are drawn on the map as are any known obstacle
database obstructions.
