4.1.4 Track undercarriage
Name Technical data
Caterpillar track
Type 750 66 150 SRT
Width 750 mm
Unloaded machine ground pres‐
sure
0.34 kg/cm
2
Loaded machine ground pressure
0.46 kg/cm
2
Travel drive
Drive type Hydro mechanical, electronically
controlled axial piston motor
Operating pressure 420 bar
Drive range stage Ⅰ 0...6 km/h (forward and reverse)
50-020-1011-900_EN
1.0 - © 2/15/2017
102
4 Technical data
4.1 Machine
