A 4-ply chain or 4-ply rope with transverse connection must be used.
The machine may only be attached using the attachment eyes for the track
undercarriage.
6.7.1 Hand signals for guidance
If the operator cannot see the working area adequately, the area in question
must be made safe by erecting fixed barriers. If this is not possible, a
banksman must provide the required guidance by hand signals for safe
transport.
The most important hand signals are described in the appendix (→ 14.1).
6.7.2 Transport components
Transport components are categorized based on information relating to the
n length,
n width,
n height,
n weight,
n attachment points,
n permitted safe working load of the attachment points and
n center of gravity
of the transport components, see (→ 14.4).
50-020-1011-900_EN
1.0 - © 2/15/2017
150
6 Transport, packing, storage
6.7 Lifting the machine
