5.4.9 Reversing camera (option)
The machine can be equipped with a reversing camera as an option.
The area behind the machine is imaged by the camera (2) and displayed on
the monitor (1). The camera and monitor are connected together via cable
(3).
The monitor is attached in the operator's cab on the right, next to the
steering wheel. The camera is attached to the rear light carrier between the
reversing lights.
Further information about the technical description of the reversing camera,
see third-party documentation (→ part 3 of the documentation).
Fig. 5.18: Technical description of the
reversing camera (option)
1 Monitor
2 Camera
3 Cable
50-020-1011-900_EN
1.0 - © 2/15/2017
139
5 Structure and function
5.4 Technical description of the optional equipment
