8.2.4 Heating/air conditioning and ventilation
8.2.4.1 Heating/air conditioning control
Setting the temperature
►
The temperature can be raised or lowered via knobs (4) and (5). The
desired temperature is shown on the display (3) in °C.
►
Knob (2) switches the air-conditioning system on/off. If the air-condi‐
tioning system is switched on, the red indicator light next to the knob will
illuminate.
Further information about operating the air-conditioning system, see third-
party documentation (→ part 3 of the documentation).
Setting the air quantity
Fig. 8.10
50-020-1011-900_EN
1.0 - © 2/15/2017
173
8 Operation
8.2 Operation of the machine
