Turn the controller (1) to the left or right.
n
Min
pos.: ventilation at lowest setting
n
Max
pos.: ventilation at highest setting
n
Off
pos.: ventilation off
►
Knob (7) switches the recirculating air function on/off. When the recircu‐
lating air function is switched on, the red indicator light next to the knob
lights up.
8.2.4.2 Round ventilation nozzle
To select the air flow direction, it is possible for the ventilation nozzle (1) to
be turned and the distributor (2) adjusted in angle.
Fig. 8.11
50-020-1011-900_EN
1.0 - © 2/15/2017
174
8 Operation
8.2 Operation of the machine
