1 Exterior mirror 2 Front working light 3 Rear window wiper
4 Combined brake/rear light 5 Reversing light 6 Windscreen wiper
The exterior mirrors (1) are electrically heated and can be adjusted electron‐
ically from the operator's cab.
The windscreen wiper (6) and the rear window wiper (3) are equipped with a
windscreen washer system.
The machine has two combination brake/rear lights (4). The reversing lights
(5) illuminate automatically when reversing. The front working lights (2) are
used for improved visibility at the working location.
Additional electrical loads of the machine are described in the sections
dealing with the operator's cab (→ 5.2.5) and optional equipment (→ 5.4).
50-020-1011-900_EN
1.0 - © 2/15/2017
119
5 Structure and function
5.2 Technical description of the basic machine (series production equipment)
