8.2.2.3 Adjusting the mirrors
►
Turn the switch (1) to select the mirror to be adjusted.
Left - Adjusting the left mirror
Right - Adjusting the right mirror
►
Adjust the mirror.
Position 2 - turn up
Position 3 - turn right
Position 4 - turn down
Position 5 - turn left
The switch is located on the right control station.
Fig. 8.4
