Warning symbol Meaning/source of danger Warning symbol Meaning/source of danger
Warning of danger (in general) Warning of machine rollover due
to slope
Warning of hot surface Warning of flammable materials
Warning of hand injury due to belt
drive
Warning of a risk of crushing due
to forces exerted from above
Tab. 3.3: Warning symbol
50-020-1011-900_EN
1.0 - © 2/15/2017
53
3 Safety
3.8 Pictograms used
