List of the safety signs on the basic machine and in the cab
Pos. Symbol Quantity Description and location
5 2 Caution: Risk of burns from hot surfaces!
Attached on the inside of the maintenance doors on the drive unit so
as to be clearly visible
- 1 Information sign with safety pictograms
Attached on the right next to the battery disconnection switch in the
cab so as to be clearly visible
Tab. 3.6: List of the safety signs on the basic machine and in the cab
50-020-1011-900_EN
1.0 - © 2/15/2017
59
3 Safety
3.10 Safety and information signs
