List of the safety signs on the round tipping trough
Pos. Symbol Quantity Description and location
1 4 Warning: Hazard of being crushed at the trough
Attached on both sides of the trough, on the outer side and on the
lower side respectively, so as to be clearly visible
Tab. 3.8: List of the safety signs on the round tipping trough
Crane (optional)
For information about the type and location of safety signs on the crane,
see third-party documentation (→ part 3 of the documentation).
50-020-1011-900_EN
1.0 - © 2/15/2017
63
3 Safety
3.10 Safety and information signs
