Name Technical data
Ground clearance approx. 610 mm
Dead weight 14750 kg
Maximum permissible weight 24750 kg
Trough - Round tipper
Loading height approx. 2076 mm
Trough capacity (level) 2000 liters
Trough capacity (heaped)
6.5 m
3
Dumping height rear approx. 1066 mm
Tipping angle trough approx. 62°
Trough height dumped approx. 5036.70 mm
Tab. 4.5: Technical data of basic vehicle with round tipper
50-020-1011-900_EN
1.0 - © 2/15/2017
94
4 Technical data
4.1 Machine
