Bernette Chicago 7 - Page 15

13
Machine Setup
• Place the thread spool on the spool pin so that the
thread comes from the front of the spool, then place
the spool cap at the end of the spool pin.
Start by raising the needle to its highest point, and also raise
the presser foot to release the tension discs.
• Pull the thread from the spool through the upper thread
guide.
• Guide the thread around the thread guide pulling the
thread through the pre-tension spring as illustrated
• Then lead it further down and around the bottom part
of the take-up lever cover.
• Pull it up and insert the thread from the right to the left
through the slotted eye of the take-up lever and then
take it downwards again.
• Guide the thread through the wire loop.
• Pull the end of the thread through the needle from the
front to the rear, and pull out about 10 cm of thread.
• Use the face plate thread cutter to cut excess needle
thread.
• Use the needle threader to thread the needle (refer to
next page for instruction).
AtteNtioN!
502020.83.11_2013_06_bernette chicago 7_EN
