87
Embroidery Setup
Details of Embroidery module
1 Embroider
2 Embroidery arm
3 USB port
4 Embroidery module release lever
5 Embroidery hoop attachment brackets
6 Hoop-securing lever
7 Embroidery module connection
8 Embroidery module connector plug
Do not touch the embroidery arm. The connector could be
damaged, and it may cause malfunctions.
Do not lift up on the embroidery arm, and do not forcefully
move it. It may cause malfunctions.
Do not carry the embroidery module by holding it at the
release button area.
The foot control is disabled as long as the embroidery
module is connected.
Note
