Machine Setup
Inserting the Bobbin
• When pushing the locking knob (1), the bobbin cover
opens.
• The bobbin cover can be pulled out of the guide (2).
• Inserting the bobbin in the bobbin holder with the
thread running in counter-clockwise direction.
AtteNtioN!
Turn power switch to «O» before threading or unthreading
the machine.
The thread take-up lever must be in the highest position
when threading. Incorrect threading can cause damages to
the machine!
A
1
2
A
B
C
B
• To make sure that the thread is pulled into the tension
spring of the bobbin holder, press a finger slightly onto
the bobbin while pulling. As a check you must feel a
resistance in the thread feed.
• Pull the thread at the arrow markings into the stitch
plate thread guide from (B) to (C).
– To cut off excess thread pull the thread back over
the cutting-off blade at point (C).
– When closing, insert the lid in the guide (2) on the
left. Afterwards press down on the right until the
locking knob (1) engages.
• Pull the thread along the arrow marking through the slit
under the finger (A) as far as the pulley (B).
AtteNtioN!
