68
Special Functions
Double Needle Sewing
Double needles must be purchased separately. They are not
include with this machine.
Make sure that the two threads used to thread the double
needle are of the same weight.You can use one or two
colors.
• Insert the double needle.
• Use only double needle assemblies with max. 2mm
needle distance Follow the instructions for single-
needle threading using the horizontal spool pin.
• Thread through the left needle.
• Insert the spool pin (included with the accessories) in
the hole on the top of the machine.
• Thread along the same path, and make sure NOT to
omit the thread guide above the needle and pass
thread through the right needle.
• Thread each needle separately.
• Select a pattern. (E.g. A Groupe Pattern 13)
• All stitch patterns can be used with Twin Needle except
for Direct Group Patterns 0 and A Group Patterns
86-99.
When using double needles, use the All- purpose foot.
Note
AtteNtioN!
Note
502020.83.11_2013_06_bernette chicago 7_EN
