Bernette Chicago 7 - Connecting the Embroidery Module

89
Align the arrow on the plug (a) with the arrow on the
machine (b).
AtteNtioN!
Embroidery Setup
Connecting the embroidery module
• Remove the sewing table to the left side.
• Move the feed dog control to lower the feed dog (b).
• Insert the embroidery module connection into the
machine connection port.
• Push lightly until the module clicks into place.
• Insert the plug into the embroidery module connector
of the machine.
Turn power switch to off («O») when carrying out any of the
following operations!
AtteNtioN!
b
a
b
a
