Bernette Chicago 7 - Removing the Embroidery Unit

90
Embroidery Setup
Removing the embroidery unit
• Remove the embroidery module connector plug.
• Press the embroidery module release button on the
left, underneath the embroidery module and slide the
module to the left to remove it.
Turn power switch to off («O») when carrying out any of the
following operations!
When you finish the work, move the feed dog control to
raise the feed dog (a).
AtteNtioN!
Note
b
b
a
a
b
b
a
a
b
a
b
a
502020.83.11_2013_06_bernette chicago 7_EN
