56926BA2, Rev. 02, 04/2019
o Show Point Values: Enables/disables the display of measurement
points on the chart when they are highlighted with the cursor.
o Un-Zoom: Undoes the last zoom operation.
o Undo all Zoom/Pan: Sets the zoom back to the start value.
o Set Scale to Default: Adjusts the axis scaling to the fluctuation of the
measured values.
3. In order to start the recording of log data on the PC, click on Recording |
<Record-Start> (Fig. 36, item 4).
4. In order to stop the recording, click on <Record-Stop> (Fig. 36, item 3).
5. Click on the selection arrows or click in the field <Sample Rate> (Fig. 36, item
8) in order to select or enter the log interval.
