5. Carefully pull out the electronics module and the scintillator/multiplier combi-
nation on the socket.
6. Remove the holder (Fig. 43, item7) with the scintillator/multiplier combination
of the electronics by loosening the four Phillips screws on the side of the
holder.
7. Pull the scintillator/multiplier combination out of the connection socket.
8. Now, the complete electronics module can be replaced.
Installing the Electronics Module
To assemble the electronics module, proceed in reverse order.
1. Replace the O-ring which seals the housing.
2. Make sure that no humidity or metal chippings are inside the connection com-
partment.
3. Carefully insert the electronics module on the socket with the scintillator/mul-
tiplier combination forward back into the housing.
4. Fasten the socket again on the detector housing. Tighten the screws alternat-
ing and equally on both sides.
5. Check and replace, if necessary, the O-ring that seals the connection compart-
ment.
6. Carefully close the connection compartment with the lid. To do this, fit the
housing cover onto the housing and tighten the Allen bolts with the specified
torque: depending on the model M5 with 4 Nm (standard values).
If you have installed a new electronics module:
• Remove the adhesive label with the Dev. ID and attach the supplied new
adhesive label.
• Reconnect the supply voltage to the detector.
• Now set the software parameters based on the list that you noted at the
beginning.
