LB 983 NightSHADE Operating Manual Technical Data
113
9 Technical Data
Camera Peltier/air-cooled slow scan CCD camera
C-Mount adapter
Resolution 1024 x 1024 Pixel x 13,6µ (back illuminated NC-100 Camera)
1004 x 1002 Pixel x 8µ (front illuminated emCCD Camera)
Quantum efficiency (max.) 90% (Luca 65%).
Noise Readout: Σ 7 e
-
RMS (Luca <1 e
-
RMS, 18 at 13,5 Mhz)
Exposure time from milliseconds to hours
Binning of pixels Variable in X- and Y-direction to increase the signal/noise ratio
Temperature Ambient temperature during operation: 10
o
to 30
o
C
Cooling temperature -80°C (NC-100) -20°C (Luca)
Ambient temperature during storage: -20
o
to 70
o
C
No condensation
Lens standard: 25mm f = 0,95
Sample chamber
Illumination internal illumination can be adjusted via the software
optional white light fluorescence illumination (400-800 nm)
Max. sample size 210 mm x 210 mm
Min. sample size 50 x 50 mm with standard lens
Dimensions Acquisition device:600 mm x 900 mm x 400 mm (WxHxD)
Camera head: 110 mm x 175 mm x 110 mm
Sample chamber (inside): 400 mm x 380 mm x 450 mm
Weight approx. 40 kg (depending on version)
Operating voltage 100-240VAC; 50-60Hz
Power rating 600VA, (max. 200VA through internal power socket)
Fuse 250V T 6,3AL
Computer Minimum requirements:
Standard PC with 3 GHz Pentium processor (MultiCore recommended)
2 GB RAM. Free USB2 port
Graphics card with 1280x1024 pixels resolution 32 bit colors, DirectX 9c Support
17" LCD monitor
Windows XP, Vista or Windows7 (32 or 64 bit)
ink-jet or laser printer
