4. Network configuration can be Static or Dynamic depending on the environment/needs but would be
configured just as a normal adapter is configured.
Virtual Guest Tagging (VGT) VLAN configuration on Virtual UVM20
Intel(r) 82574L Gigabit Network Connection (Intel E1000)
To install the required driver within a Windows 2012 R2 guest operating system:
1. Download ProWinx64 from Intel located here: http://downloadmirror.intel.com/18718/eng/PROWinx64.exe
Use 7zip to extract contents to a temp folder.
2. Right-click the network adapter and click Update Driver Software.
3. Click Browse my computer for driver software.
4. Click Let me pick from a list of device drivers on my computer.
5. Click Have Disk.
6. Click Browse.
7. Browse to temp location driver files were extracted to.
8. Click Next to install the driver.
9. Repeat Steps 2-8 for each network adapter you have for the virtual machine.
10. After all the adapters are updated, run the PROWinx64.exe file, rather than extracting it. You should now be
able to install the Advanced Network Services software with VLANs.
To configure VLAN tagging on a Virtual Machine:
1. Open Device Manager.
2. Right-click Network Adapter and select Properties.
There will now be a VLANs tab available. This is not displayed before installing the PROWinx64.exe file above.
3. Click New.
4. Enter VLAN ID (for example, 20).
5. Enter VLAN Name (for example, VLAN20).
6. Click OK.
7. Continue these steps for as many VLAN’s that are required.
Appendix A: Configuring VLAN
UVM Appliance User Guide 55 © 2018. BeyondTrust Software, Inc.
