AS-i/PROFIBUS Gateway Operating by Full-graphic Display
Subject to reasonable modifications due to technical advances Copyright Bihl+Wiedemann, Printed in Germany
Bihl+Wiedemann GmbH · D-68199 Mannheim · Phone +49-621-339960 · Fax +49-621-3392239 · Internet http://www.bihl-wiedemann.de
issue date 7.1.2002
44
6.3.5 Parameter
This function shows the hexadecimal value of the actual AS
-
i paramerters for all
AS
-
i slaves.
The actual AS
-
i parameters can be changed after selecting the desired slave ad-
dress.
6.4 Diagnosis (Normal AS
-
i Diagnosis)
The menue "Diagnosis" enables you to choose one of the following submenues:
• EC-Flags (Execution control flags)
• Actual Config (actual configuration)
• LPF (list of periphery faults)
• AS-i Master (Info)
6.4.1 EC-Flags (Execution Control Flags)
This function shows the EC-flags hexadecimal, binary and as single bits beginning
with the lowest-order bit.
Bit 0: Config_OK
Bit 1: Normal_Op.
Bit 2: LDS.0
Bit 3: Auto_Addr_Asn
Bit 4: Auto_Addr_Avl
Bit 5: Config_Active
Bit 6: AS-i_Pwr_Fail
Bit 7: Offline_Ready
Bit 8: Periphery_OK
See also "GET_FLAGS", page 71.
