AS-i/PROFIBUS Gateway PROFIBUS-DP
Subject to reasonable modifications due to technical advances Copyright Bihl+Wiedemann, Printed in Germany
Bihl+Wiedemann GmbH · D-68199 Mannheim · Phone +49-621-339960 · Fax +49-621-3392239 · Internet http://www.bihl-wiedemann.de
issue date 7.1.2002
93
The diagnosis data field of the safety monitor has following structure:
8.3.3.3 Integrated AS-i Sensors: Warnings
Function: 03
16
List of integrated AS-i sensors according to profil S-1.1 (without advanced addres-
sing) or profil S-3.A.1(with advanced addressing), by which the input data bit D1
("Warning") is deleted.
For building of this list CDI and IDI are utilized only. Integrated AS-i slaves, which
are projected but not existing, are entered therfore not here.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
000
16
1 monitor state
2 state circuit 1
3 state circuit 2
4 number circuit 1
5 number circuit 2
6 device index 32, circuit 1
7 device color, circuit 1
8 device index 33, circuit 1
9 device color, circuit 1
……
68 device index 63, circuit 1
69 device color, circuit 1
70 device index 32, circuit 2
71 device color, circuit 2
……
132 device index 63, circuit 2
133 device color, circuit 2
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
17E
16
2T O circuit
303
16
