8.1.3 I/O-Data
8.1.3.1 AS-i V2.04 Easy Mode
8.1.3.2 AS-i V2.1 Mode
Process data
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 slave 1/1A flags
D3 D2 D1 D0 F3 F2 F1 F0
1 slave 3/3A slave 2/2A
2 slave 5/5A slave 4/4A
3 slave 7/7A slave 6/6A
4 slave 9/9A slave 8/8A
5 slave 11/11A slave 10/10A
6 slave 13/13A slave 12/12A
7 slave 15/15A slave 14/14A
8 slave 17/17A slave 16/16A
9 slave 19/19A slave 18/18A
10 slave 21/21A slave 20/20A
11 slave 23/23A slave 22/22A
12 slave 25/25A slave 24/24A
13 slave 27/27A slave 26/26A
14 slave 29/29A slave 28/28A
15 slave 31/31A slave 30/30A
In V2.1 mode the AS-i I/O data are mapped in the PROFIBUS pro-
cess data as known from the Siemens and AS-i/InterBus masters.
That means the lower nibble describes the data of the AS-i slave
with the higher slave address. The EC flags resp. HI-flags are addi-
tionaly mapped at the nibble of AS-i slave 0.
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 flags slave 1/1A
F3 F2 F1 F0 D3 D2 D1 D0
1 slave 2/2A slave 3/3A
2 slave 4/4A slave 5/5A
3 slave 6/6A slave 7/7A
4 slave 8/8A slave 9/9A
5 slave 10/10A slave 11/11A
6 slave 12/12A slave 13/13A
7 slave 14/14A slave 15/15A
8 slave 16/16A slave 17/17A
9 slave 18/18A slave 19/19A
