8.3.2.46 INVERTER
With that call an AS-i slave for frequency inverters is switched to the mode to get
four 16 bit values via the AS-i analog profile 7.3 and afterwards switched to the
selcted destination parameter.
8.3.2.47 FP_PARAM
This command is used for parametrization of "functional profiles".
The content of the request and response bytes is depending of the called function
(see chapter 8.3.3).
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
17C
16
2T – circuit
3 slave address
4 destination parameter
5 value 1, high byte
6 value 1, low byte
7 value 2, high byte
8 value 2, low byte
9 value 3, high byte
10 value 3, low byte
11 value 4, high byte
12 value 4, low byte
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
17C
16
2T result
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
17D
16
2T – circuit
3function
4 request byte 1
……
n request byte n-3
