8.3.2.23 GET_LPF
With this call, the list of peripheral faults (LPF) signaled by the AS-i slaves is read
out from the AS-i master. The LPF is updated cyclically by the AS-i master. Whe-
ther an when an AS-i slave signals faults of the attached peripherals (for example
wire break) can be found in the description of the AS-i slave.
8.3.2.24 Write AS-i Slave Extended ID1 (WRITE_XID1)
With this call, the extended ID1 code of an AS-i slave with address "0" can be writ-
ten directly over the AS-i cable. The call is intended for diagnostic purposes and is
not required in the normal master mode.
The AS-i master passes on the extended ID1 code to the AS-i slave without any
plausibility check.
