AS-i/PROFIBUS Gateway PROFIBUS-DP
Subject to reasonable modifications due to technical advances Copyright Bihl+Wiedemann, Printed in Germany
Bihl+Wiedemann GmbH · D-68199 Mannheim · Phone +49-621-339960 · Fax +49-621-3392239 · Internet http://www.bihl-wiedemann.de
issue date 7.1.2002
61
SLAVE_ADDR 0D
16
Change_Slave_Address 4 2
SET_AAE 0B
16
Set_Auto_Adress_Enable 3 2
GET_LPF 3E
16
Get_LPF 2 10
WRITE_XID1 3F
16
Write_Extended_ID-Code_1 3 2
RD_7X_IN 50
16
Read 1 7.3-slave in.data 3 10
WR_7X_OUT 51
16
Write 1 7.3-slave out.data 11 2
RD_7X_OUT 52
16
Read 1 7.3-slave out.data 3 10
RD_7X_IN_X 53
16
Read 4 7.3-slaves in.data 3 34
WR_7X_OUT_X 54
16
Write 4 7.3-slaves out.data 35 2
RD_7X_OUT_X 55
16
Read 4 7.3-slaves out.data 3 34
READ_ODI 56
16
Read ODI 2 34
WR_74_PARAM 5A
16
Write S-7.4-slave parameter ≥62
RD_74_PARAM 5B
16
Read S-7.4-slave parameter 4 ≥3
RD_74_ID 5C
16
Read S-7.4-slave ID string 4 ≥3
RD_74_DIAG 5D
16
Read S-7.4-slave diagnosis string 4 ≥3
GET_LISTS 30
16
Get LDS, LAS, LPS, Flags 2 29
GET_LCS 60
16
Get LCS 2 10
GET_LOS 61
16
GET_LOS 2 10
SET_LOS 62
16
SET_LOS 10 2
GET_TECA 63
16
Get transm.err.counters 2 34
GET_TECB 64
16
Get transm.err.counters 2 34
GET_TEC_X 66
16
Get transm.err.counters 4 34
EXT_DIAG 71
16
ExtDiag generation 6 2
BUTTONS 75
16
Disable pushbuttons 3 2
RD_EXT_DIAG 7B
16
Read ExtDiag Settings 2 7
INVERTER 7C
16
Configure Inverter Slaves 12 4
FP_PARAM 7D
16
„Functional Profile“ Param. ≥3 ≥2
FP_DATA 7E
16
„Functional Profile“ Data ≥3 ≥2
Values for command
command value meaning
Req
Len
Res
Len
