1.6 Rear Panel Overview
Figure 1.5 – Rear Panel Overview
Rear Panel Description
Output and remote sense terminals
USB interface
RS-485 interface
Analog programming interface (DB25 connector)
AC input receptacle
Earth ground connection
GPIB interface
Ethernet (LAN) interface
RS-232 interface
1
4
8
5
9
7
2
6
3
1
2
3
4
5
6
7
8
9
