33
3. Select one of the settings wanted during power up, and press
to save changes. If USER has been selected, set user
defined voltage, current and output state.
4. To exit the menu at any time, press twice.
3.6 CONFIG Menu
All setup procedures and settings explained in this section can be
accessed from the CONFIG menu. To access this menu, press ,
press 1 time and select CONFIG, then press .
Output Limit Settings
The voltage or current output limits can be configured to provide limit
protection to prevent accidental changes to the output settings. There
are four limit values that can be set: voltage maximum (VMAX), voltage
minimum (VMIN), current maximum (IMAX), and current minimum
(IMIN).
