27
3.5 SYSTEM Menu
All setup procedures and settings explained in this section can be
accessed from the SYSTEM menu. To access this menu, press .
When SYSTEM is blinking, press .
Remote Communication Configuration
To set up remote interface connections and settings, refer to chapter “4
Remote Operation”.
Save/Recall Instrument Settings
The instrument can save up to 100 voltage/current values for quick
recall access. Memory is allocated in 10 different storage groups (group
0 to 9), and each group has 10 memory locations to store settings (0 to
9). The memory group must be selected from the menu first, before
settings can be saved within the group.
Select Storage Group
1. From the SYSTEM menu, press button 1 time to select
Memory and press . The following screen will appear.
To Next Page
