BK Precision PVS10005 User Manual

28
2. Use the rotary knob or the numeric keypad to enter the storage
group. Select between 0 – 9. Press to save selection.
3. To exit the menu at any time, press twice.
Save Settings
1. Set up output voltage and current settings that you want to
save.
2. Then, press and . The display will show the following:
3. Use the current adjust knob or the numeric keypad to enter the
memory location in which to store current instrument settings.
Select between 0 – 9. Press to save to the selection
location.
Recall Settings
1. Press to enter the Recall mode. The current group number
is shown on the display.

BK Precision PVS10005 Specifications

General

Output Current	0-5 A
Number of Outputs	1
Display Type	LCD
Weight	4.5 kg (9.9 lbs)
Current Resolution	1 mA
Load Regulation (CV)	≤ 0.01% + 2 mV
Line Regulation (CV)	≤ 0.01% + 2 mV
Temperature Coefficient	≤ 100 ppm/°C
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Input Voltage	100 - 240 VAC, 50/60 Hz
Current Accuracy	0.1% + 5 mA
Humidity	Up to 80% RH, non-condensing
Cooling	Fan
