21
8. To exit the menu at any time, press twice.
3.2 Configure Voltage/Current Output
Voltage and current can be set from the front panel. Remote sense is
also available on the rear panel for voltage compensation at the output.
Setting Voltage
Follow the steps below to set the output voltage:
1. From the normal front panel display, users can use either the
voltage adjust knob or the numeric keypad to enter the setting
voltage.
2. If entering using numeric keypad, press first so that the
cursor selects the voltage display. Then, enter the value and
press to set the voltage.
3. To change the cursor position to adjust with the voltage adjust
knob, use the keys to move left or right.
Note: To see the changes to the setting voltage, be sure the
display is not showing the measured voltage. This can be
checked by looking at the LED next to the button. If it
is not lit, the display is showing the setting voltage.
When output is ON, the user can use the rotary to adjust the voltage
value when the output is in constant voltage (CV) mode. The output
value will change simultaneously with the adjusted value. This is so
called on-the-fly function that allows user to easily change the output
