BK Precision PVS10005

32
GPIB
Address
1
1
RS-232C
Baud, parity, data, stop
9600, N, 8, 1
9600, N, 8, 1
RS-485
Baud, parity, data, stop
9600, N, 8, 1
9600, N, 8, 1
Address
1
1
LAN
Mode
AUTO
AUTO
IP address
0.0.0.0
0.0.0.0
Mask address
0.0.0.0
0.0.0.0
Gateway address
0.0.0.0
0.0.0.0
Configure Power-On State
The initial Power-On state of the power supply can be configured
(voltage, current, output state) by following the steps below:
1. From the SYSTEM menu, press button 4 times to select
PON STAT and press .
2. There are three options which can be selected using the rotary
knob:
OFF – Last voltage and current values before power off and
output state is OFF.
LAST – Last voltage, current, and output state values before
power OFF.
USER – User defined voltage, current, and output state.
