66
3. Use the buttons to move the cursor to the ON/OFF
parameter and use the rotary knob to change ON or OFF.
4. Press to complete the timer setting.
5. Pressing the key will enable the output and start the timer.
3.10 Slew Rate Setting
The power supply has the capability of controlling the output voltage
and current slew rate. The timing can be configured for the rising/falling
edge between voltage and current output transitions.
Follow the steps below to configure the voltage or current slope .
1. Press and buttons to enter the slope menu.
2. Use the buttons to select VOLTAGE or CURRENT and
press to confirm. The following will be displayed:
3. Use the keypad or rotary knob to enter the slope value and
press to confirm.
4. Press to exit the slope menu.
