22
value if the test is needed.
Setting Current
Follow the steps below to set the output current:
1. From the normal front panel display, users can use either the
current adjust knob or the numeric keypad to enter the setting
current.
2. If entering using numeric keypad, press first so that the
cursor selects the current display. Then, enter the value and
press to set the current.
3. To change the cursor position to adjust with the voltage adjust
knob, use the keys to move left or right.
Note: To see the changes to the setting current, be sure the
display is not showing the measured current. This can be
checked by looking at the LED next to the button. If it
is not lit, the display is showing setting current.
When output is ON, the user can use the rotary to adjust the current
value when the output is in constant current (CC) mode. The output
value will change simultaneously with the adjusted value. This is so
called on-the-fly function that allows user to easily change the output
value if the test is needed.
