BK Precision PVS10005

19
3 Front Panel Operation
3.1 Menu Options
All settings and parameters can be configured from the built-in menu
system of the power supply. To access the menu, press .
The menu system is divided into 5 sections and are organized as follows:
SYSTEM
COMM
Select and configure communication interface.
MEMORY
Select memory location for save/recall
instrument settings.
BEEP
Enable/Disable key sound.
DEFAULT
Select memory location for save/recall
instrument settings.
PON STAT
Configure power-on state.
CONFIG
LIMIT
Configures voltage setting limits.
PROTECT
Configures OVP, OCP, OPP, CV to CC, and CC to
CV protection.
EXTCTRL
Configures external analog control.
PARALLEL
Configures parallel connection and
master/slave mode.
PV SIM
Configures photovoltaic array simulator
function.
INFO
Shows model, firmware version,
communications settings, optional modules
install and other power supply information.
CAL
Calibration menu.
