34
Figure 3.2 – Output Limit Settings Graph
Note: At any time during operation, when you are unable to set
to a desired voltage or current, check these limit settings to
make sure the set value is within the limit’s range.
The shaded area illustrated above is the settable range of the output
voltage and current.
Follow the steps below to configure the output limits:
1. From the CONFIG menu, select LIMIT, then press . The
following screen will display:
